Open-Mesh GRP Grating Panels - 25mm, 38mm, 50mm
Open-Mesh GRP Grating offers a robust flooring panel system for commercial and industrial environments - for walkways, platforms, riser voids, and gantry applications.
GRP Grating is extremely strong and durable, yet 50% lighter than steel alternatives for a swift installation. The open-mesh profile provides excellent drainage and ventilation properties.
SureGRP offer a complete supply and fabrication service - with fast nationwide delivery. We stock a large volume of grating products in a variety of sizes, thicknesses, and colours.
We supply GRP Flooring to match your requirements nationwide. They offer a long-term, low-maintenance solution for maintaining a safe working environment.
Contact Our Customer Service Team via telephone on 01952 583 055. Email us at info@suregrip.co.uk.
Product Overview
Open-Mesh GRP Grating Panels offer a cost-effective, zero-maintenance, structural flooring panel system - which benefits from a strong resistance to chemicals, corrosion, and wear.
They are ideal for commercial and industrial environments. Typical applications include walkways, riser voids, gantries, bridges, ramps, and platforms.
GRP Grating offers exceptional strength and durability, yet remains lightweight and easy to maneuver during installations.
Open-Mesh Profiles cater for drainage and ball-proof test requirements, whilst providing excellent ventilation, allowing air to circulate freely. This solves concerns within industrial and commercial environments, where heat or fumes may be present.
Additionally, the open-apertures provide highly effective liquid drainage, averting the build-up of water that could create a risk of slipping. This feature is particularly beneficial in outdoor or industrial environments where moisture or spills are common.
As standard, our flooring products feature an excellent anti-slip surface finish, which surpasses the industry standard slip resistance criteria.
We supply to match your requirements, with fast nationwide delivery as standard. GRP Grating Panels are stocked in a wide range of sizes, thicknesses, and colours.
Benefits of Open Mesh GRP Grating.
GRP (Glass-Reinforced-Plastic) Fibreglass materials benefit from high-resistance to chemicals, corrosion and wear - providing an exceptional alternative to steel grating.
This ensures a durable design which will retain an aesthetic appeal for an extended lifetime. As a result, there is no frequent need for repairs or replacements.
GRP Grating is 50% lighter than Steel Grating alternatives, which ensures a swift installation process.
Fibreglass Grating is fire-rated to ASTM-E-84 compliance standards, with non-sparking, non-conductive characteristics.
Typical Applications | Suitable Environments |
Open-Mesh GRP Grating is commonly used for applications such as:
| GRP Grating Panels are specified for use within commercial and industrial environments such as:
|
GRP Grating - Product Options
SureGRP stock a wide variety of GRP Grating Panels in a variety of profiles, panel sizes, thicknesses, and colours.
Grating Types
Standard Open-Mesh Grating features a 38mm x 38mm open-square profile. Alternative aperture sizes are available.
Additionally, we offer the following alternative profiles:
Mini Mesh Grating (Also known as Micro-Mesh) - featuring smaller apertures.
Solid Top Grating - which features a closed, solid surface finish with no openings across the walkway surface.
Open-Mesh GRP Grating Panel - Specification Options
Size Options
We stock a large volume of grating in a variety of sizes - up to 4038mm in length, and 1200mm wide.
Full Panel Sizes
We offer a selection of full-sized panels in stock, which are available to buy on the website.
Alternatively, we offer custom cut-to-size panels, made to your requirements.
The following sizes are currently in-stock and available to purchase online -
2000mm x 1000mm
3000mm x 1000mm
3660mm x 1220mm
4038mm x 1000mm
Made-to-Measure Service: Cut to Size Panels.
SureGRP offer a state of the art fabrication service. We have a complete in-house facility to accomodate for cut-to-size requirements.
We can fabricate panels to your exact size and shape requirements to match your specifications.
Thickness Options
GRP Grating Panels in 25mm, 38mm, 50mm Standard Thicknesses.
When purchasing online or requesting a quote, determine the appropriate panel for your application - carefully considering load and span capacities and individual requirements.
Colour Options
Our most popular colours are Light Grey, Dark Grey, Yellow, and Green. Bespoke alternatives are available.
Surface Finish Options
GRP Walkway Grating features an industry-leading anti-slip surface. This enhances safety practice to prevent slips, trips and falls within wet, icy, and oily conditions.
The slip-resistant surface surpasses BS-7976 standards and classes as enhanced non-slip surface finish.
Plain (Concave) GRP Mesh Grating profiles are also available without the slip-resistant finish.
GRP Grating - Technical Specification.
Purpose
Open-Mesh Grating Panels are a type of modular structural walkway flooring panel. They can support structural loads and cover open voids.
The open profile is designed to cater for drainage requirements and conforms to ball-proofing regulations.
Standard Open Mesh Grating Panels feature the industry-standard 38mm x 38mm openings.
Alternatives, both smaller and larger - including 50mm x 50mm are also in-stock and are available on request.
Material
Made from a hardwearing and durable GRP (Glass-Reinforced-Plastic) material, the fibreglass material has robust properties. This ensures the panel is very strong, impact resistant, and long-lasting.
GRP Grating is produced using resin as the matrix and continuous interwoven glass fibres as the reinforcement material. The GRP (Glass-Reinforced-Plastic) forms uniformly through a mould system. This creates a high-strength profile with structural characteristics.
GRP Grating is therefore suitable for structural applications within high-footfall, commercial and industrial environments.
Fire Resistance
Fibreglass Walkway Grating is fire-resistant to ASTM-E-84 compliance standards, with non-sparking, non-conductive characteristics.
GRP Open Mesh Flooring is designed as an electric, magnetic, and thermal insulator.
This achieves ASTM E84 standard for flame spread and smoke development.
Installation Process
GRP Grating Installation is a simple process.
We supply pre-cut panels, or alternatively, you can cut to size on-site.
GRP materials are usually 50% lighter than steel alternatives. This ensures the system is easily transportable and manourvable on-site. (See further guidance in the weights table below).
GRP Grating Clips and bolts fix the panels to the substrate and connect adjoining panels together. This allows for easy adaptation to different layouts or configurations, ensuring a seamless installation onto new or existing structures.
Typical Grating Panel Weights
GRP (Glass-Reinforced-Plastic), or FRP (Fibre-Reinforced-Plastic) Panels benefit from an impressive strength to weight ratio.
Find our typical product weights in the table below:
GRP Grating Panel Weights(3660mm x 1220mm) |
|
|---|---|
Type | Weight |
25mm GRP Grating | 55 KG |
38mm GRP Grating | 85 KG |
50mm GRP Grating | 90 KG |
